Type

Speed

(Gbps)

Conductor

Insulation

Drain

Size

Impedance
(Ω)

Intra Skew
(ps/m max)

IL@8Ghz
(dB/m Nom)

IL@12Ghz
(dB/m Nom)

IL@16Ghz
(dB/m Nom)

AWG

Material

Material

ID/mm

AWG

Material

L(mm)

W（mm）

PCIE4.0

16

30

SC

FEP

0.65

32

TC

0.79

1.84

85±5

10

5.7

7.1

8.9

32

SC

FEP

0.48

34

TC

0.62

1.42

10

6.8

8.4

11.8

34

SC

FEP

0.40

34

TC

0.54

1.26

10

8.0

10.0

13.8
