Type |
Speed (Gbps) |
Conductor |
Insulation |
Drain |
Size |
Impedance
(Ω)
|
Intra Skew
(ps/m max)
|
IL@8Ghz
(dB/m Nom)
|
IL@16Ghz
(dB/m Nom)
|
IL@32Ghz
(dB/m Nom)
|
||||
|
AWG |
Material |
Material |
ID/mm |
AWG |
Material |
L(mm) |
W（mm） |
|||||||
|
PCIE6.0 |
64 |
29 |
SC |
FEP+PTFE |
0.55 |
34 |
TC |
1.18 |
1.78 |
85±5 |
4 |
3.23 |
4.6 |
7.8 |
|
30 |
SC |
FEP+PTFE |
0.49 |
34 |
TC |
1.05 |
1.55 |
4 |
3.7 |
5.0 |
7.8 |
|||
